Description
xThis compact multi-deck rotary selector switch features twelve discrete positions across two wafers, combining a slim M8 profile with reliable performance for complex PCB-mounted applications. It offers high-reliability gold-plated contacts and a 30° detent angle, delivering consistent indexing and robust switching action. Designed for demanding environments, it’s ideal for use in precision industrial, aerospace, and defense modules where space-efficient, dependable switching is required.
Product Features
x- 30° indexing angle
- From 1 x 12 to 4 x 3 poles per positon per wafer
- Gold plated contacts
- IP60 or IP68 shaft / front planel sealing
- Ø 3, 4 or 6 mm stainless steel shaft
- Operating temperature from -40 to +85 °C
- Shorting or non-shorting
- Soldering eyelets or pins for PCB
- Endless rotating or with end stop
- Various options and customizations available
Product Information
xItem/Part Number01-2xxx-20/70xx-12-0
Item Description01 with pins for PCB | 12 positions | M8 | 2 wafers
