Description
x3U CompactPCI Serial Backplane with 7 CompactPCI S.0 slots, system slot right, with rear IO: 1x CompactPCI S.0 CPU slot, 6x CompactPCI S.0 peripheral slots, with connectors for RTMs, Ethernet single star from system slot to all peripheral slots
Product Features
x- CompactPCI Serial (PICMG CompactPCI-S.0) compliant backplane
- High-speed connectors supporting data transfer rates up to 12Gbps in all 7 slots
- Single star topology for serial interfaces such as PCI Express, SATA, USB2 and USB3 are provided by the CPCI S.0 system slot
- Europacard form factor in 3U height
- Ethernet routed as single star from system slot to all peripheral slots
- Designed to support Rear Transition Modules
- With RTM connectors
Product Information
xItem/Part Number1CPCIS-307-R110
Item Description3U CompactPCI Serial 7-slot SSR w/ RTM w/ Ethernet
ArchitectureCPCI Serial
Slots7
