Description
xThe 565x family of 6U VPX Storage Modules provide the ability to access up to three 2.5” solid state hard drives in a single slot. Conduction and air cooled versions bring high capacity storage array capability to rugged environments.
Product Features
x- Three solid state drives in a single slot. Designed to provide SATA I/O access via data plane connections in OpenVPX backplanes, it may be used singularly or integrated as part of a multi-slot storage array using an external SATA RAID controller.
- Choose the latest solid state drive technology for your application
- 6Gbps data rates are supported (external controller dependent
- Standard 6U x 5HP x 160mm OpenVPX form factor
- Drive activity LEDs media dependent
- Extended temperature operation from -40°C to +75°C
- Conduction or air cooled option
- VITA 48.1 REDI primary and secondary covers
- Optional rear transition module
- A lab version is available with DVD and single 2.5” drive.
Product Information
xItem/Part Number565x
Item Description6U OpenVPX Three Drive Storage Module Family, 565x
ArchitectureVPX/OpenVPX
Datasheets and Media
xDatasheet:
