Description
xDesigned to align with SOSA™, Elma’s VPX Chassis Manager assures the proper operation of the chassis and boards in defense embedded computing platforms. It monitors the health of the chassis, reports anomalies and takes actions when needed.
Product Features
x- Aligned to the SOSA Technical Standard Version 1.0, VITA 46.11 Tier 3, with firewall support and SOSA out-of-band command support
- IPMI Chassis Manager with redundant IPMB to maximize uptime
- Web based Graphical User Interface monitors up to 12 fans, 8 analog inputs and 6 external thermistors for temperature measurements
- Provides 16 digital inputs and 16 configurable digital outputs
- Sensor Event Log and cooling control
- Available in the following form factors: stand-alone (79-V46-CHMC-CMX-S1), 3U air-cooled plug-in card (79-V46-3-CHMC-CMA-S1); and 3U & 6U conduction cooled plug-in cards (79-V46-3-CHMC-CMC-S1, 79-V46-6-CHMC-CMC-S1)
- Ask about our range of partner processors, switches and payload bards as well as sub-system integration and test.
Product Information
xItem/Part Number79-V46-CHMC-x-CHMC-CMx-S1
Item DescriptionSOSA Aligned Family of Chassis Managers, VITA 46.11
ArchitectureVPX/OpenVPX and SOSA
Datasheets and Media
xDatasheet:
Technical Guide:
