OpenVPX Backplanes

Elma has served the defense industry needs for years and is a key participant in open standards organizations such as VITA and SOSA®.
Elma has served the defense industry needs for years and is a key participant in open standards organizations such as VITA and SOSA®.
As the leader in open standards backplane design and manufacturing, our cutting-edge signal integrity analysis informs the designs of our high-speed backplanes, handling critical data at high performance speeds.

A longtime member and contributor to the VITA open standards, Elma offers the widest range of 3U and 6U backplanes that comply with VITA 65 OpenVPX.

Elma is also a major participant in and contributor to open standards that support the DoD’s mandated initiatives under the Modular Open Standards Approach. Elma’s backplanes are designed in alignment with The Open Group® Sensor Open Systems Architecture® Technical Standard, or SOSA®, in slot counts from 2 to 12. The backplanes support high-speed signals on all data paths and VITA 67.3 fiber connectors and VITA 66.5 optical connectors.

All of our field-proven backplanes provide the foundation for up to 100Gbps performance for mission-critical systems requiring lower life-cycle costs and rapid technology insertion. They enable complex, high speed signal processing systems with the latest optical fiber and RF connectivity as well as slot profiles for SBCs and payload expansion.

Developers can use the development backplanes as configured or work with Elma to identify your specific profile configuration needs.

Below is a list of our Interactive Backplane Selector Charts. They provide a list of the available backplanes with their compatible slot profiles. Mouse over the backplane model number, and it will show the backplane topology at a glance. The product page link is in the far right column.

Or, you can always connect with our technical sales team for help in your selection.

Download one of our interactive charts:

Interactive Chart for 3U SOSA Aligned Backplanes

Interactive Chart for 3U OpenVPX Backplanes

Interactive Chart for 6U OpenVPX Backplanes

Interactive Chart for 3U Power & Ground-Only Backplanes

Interactive Chart for 6U Power & Ground-Only Backplanes

Interactive Chart for 3U & 6U OpenVPX Accessories

All OpenVPX Backplanes
