Description
xDesigned for RF-intensive prototyping, this backplane features an installed VITA 67.1 connector in the J2 slot. It provides a dedicated path for coaxial RF signals while ensuring consistent power distribution across the utility plane. All P1-P6 pins are user-defined, offering maximum flexibility for custom cable-to-bulkhead configurations.
Product Features
x- Compliant to VITA 46 specifications
- Versions available support VITA 66 (fiber optic) and VITA 67 (RF) modules
- Power and ground only backplane for simple and low-cost development
- 3.3V, 5V, and 12V power
- P1- P6 pins are user-defined
- Backplanes have the utility plane implemented in P0 and P13
- NVMRO, SYSRESET#, SYSCON# and maskable reset are supported
Product Information
xItem/Part Number101V301P03-9002R
Item Description3U VPX 1 -Slot Power & Ground with VITA 67.1 Connector installed J2
ArchitectureVPX/OpenVPX
Slots1
