Description
xHold-Up power module for voltage inputs from 16 to 36VDC provides up to 330W of hold-up power for 50ms. Designed in compliance with MIL-STD-704 / DO160. The board can be ordered as a fixed mount or plug-in version.
Product Features
x- Input voltage: 16-36 VDC
- Maximum power: 330W | Hold up time: 50ms for up to 330W |
- Under voltage trigger level: 17.3 VDC | over voltage protection per MIL-STD 704A-F
- Reverse voltage protection: max -40 VDC
- Inrush current: max. 3.5 A
- Capacitor load current: max- 1.5 A
- Operating temperature: -40 to +85°C | Storage temperature: -40 to +85°C
- Electromagnetic compatibility: according to MIL-STD 461F
- Shock & Vibration testing to MIL-STD-810F
- Humidity: 95% non-condensing
Product Information
xItem/Part Number064-474
Item DescriptionHold-Up Power Module with optional cover
